Supply Automatic Accurate Batching Machine Manufacturer

Dealing Material: the automatic accurate batching machine can process all solid materials, Capacity: 1-50 ton/hour Application: the automatic accurate batching machine can use for fertilizer, chemical, mining, metallurgy, construction,etc. Advantages: automatic operation, high accurate batching with dosing system, easy operation, large capacity

Get price Send us

Automatic Accurate Batching Machine For Sale



Technical Parameter of Automatic Batching Machine



Model GTDP-2 GTDP-3 GTDP-4 GTDP-5 GTDP-6 GTDP-8
Hopper Size 1200*1200,1500*1500,1800*1800,2000*2000,2200*2200,2400*2400
Ingredients Types 2 3 4 5 6 8
Weighing Accuracy ≤0.2%
Weighing Belt B500-1000
Motor Power 2*1.1kw 3*1.1kw 4*1.1kw 5*1.1kw 5*1.1kw 6*1.1kw
Control PLC Central Control



Introduction of Automatic Batching Machine



we are the automatic accurate batching machine manufacturer and automatic accurate batching machine factory, PLZ series automatic batching machine is mainly suitable for 3 to 10 kinds of the material feeding , dosing and mixing , which use the PLC for automatic control, with pneumatic cylinder for main quantitative feeding control and prevent the materials dropping from the feed hopper , material after mixing with a belt machine automatically sent out.

https://youtu.be/UHXODb1B6PQ

Batching Machine

Performance Features of Automatic Batching Machine



1.Fully automatic batching and dosing system
2.various capacity from 5 to 100 tons per hour
3.the Automatic Batching Machine can work with 3 to 10 kinds of raw materials
4.batching accuracy ≤ ± 0.2%
5.According to users needs, can switch the formula at any time
6.With print function, you can print the report at any time
7.With on-site or remote monitoring system function, connected with a large screen display the current recipe
8.Small footprint (ground-type, semi-underground, underground), low power consumption, simple operation. Easy to maintain, reduce investment costs.

Batching Machine

Working Principle of Automatic Batching Machine



Automatic batching system supplier is a kind of automatic batching machine that can be used with BB fertilizer equipment, organic fertilizer equipment, compound fertilizer equipment and NPK compound fertilizer equipment. It can complete the automatic proportioning and batching according to customer demand. The machine is used for weighing a variety of raw materials, distribution mixing, instead of manual table or volumetric measurement of the way. With high precision measurement, distribution efficiency, high degree of automation, is a complete set of fertilizer production equipment in one of the main. The product uses computer control, electronic monitoring, digital prompts, control functions, easy operation, precision fertilizer products is the protection.

Batching Machine

Dynamic automatic batching machine price for continuous batching requirements of the site, such as fertilizer ingredients, coking ingredients. These sites on the ingredients of the continuity of the higher requirements generally do not allow intermediate ingredients to stop the situation, the ratio of various materials require more stringent. Dynamic automatic batching system measurement generally use the belt scale or nuclear scale as a measurement device, the host has a PID adjustment and alarm function, can achieve a warehouse of automatic control.
