Why buy the Gate Roller Granulator for fertilizer?

Fertilizer-to-roll extrusion granulator is the key equipment of NPK compound fertilizer granulator. The fertilizer-roller extrusion granulator uses the extrusion principle to form fertilizer granules with a diameter of 3-10mm at one time. The shape and size of the ball socket on the roller housing can be customized by the customer. The granulation rate of the roll extrusion granulator is higher than 95%. Using non-drying technology, the material is pressed into a spherical shape to meet the requirements of compound fertilizer production.

Working principle of double-roll extrusion granulator:

The principle of fertilizer-to-roller extrusion granulator is that the motor drives the belt and the pulley, and then transmits it to the drive shaft through the reducer, and synchronizes the open gear with the passive shaft to achieve the same direction. Extruded in the rolls of a fertilizer-roller extrusion granulator. After demoulding and pelletizing, add material from the hopper; transfer the material to the crushing screening studio through a chain, screen and separate the finished product (pellets), Then return to mix with the new material and granulate again.

Commitment to roll granulator quality:

1. The steel of the roll granulator adopts Anshan Iron and Steel Q235 plate, and the channel steel, square steel and other plates are national standards.
2. The equipment motor is a large-scale national standard copper-core motor. The warranty period is 1 year. If there is a quality problem within 1 year, it will be replaced with a free one.
3. The reducer of the roller granulator has a warranty of 1 year, and if there is a quality problem within 1 year, it will be replaced free of charge.
4. The complete set of gears, ring gears and rolling rings are made of # 45 cast steel parts, which are not damaged by external forces, and can be replaced free of charge within 1 year.
