Gate new type animal manure disc fertilizer granulator

The new type organic fertilizer granulator uses high speed rotating mechanical shearing force and the resulting air power, making continuous implementation of the fine powder material in the machine mixing, granulating, spheroidizing, density and other processes, which achieves the goal of the granulation. The granulation method makes the pellet rate higher, and the granule is more beautiful, while saving energy and improving efficiency.

Characteristics of Performance

The principle is simple, and the granulation speed is fast; using high speed rotating mechanical shearing force and the resulting air power makes continuous implementation of the fine powder material in the machine mixing, granulating, spheroidizing, density and other processes.

The granule quality is high and the machine is especially suitable for granulation of light powder materials. Finer particles of fine powder, higher sphericity of granules, and higher pellets quality.

No bond is required; using the particles of organic matter to be interbred with each other under certain forces, so no bond is needed for granulation.

Wide source of materials, including livestock and poultry manure, compost fertilizer, sea fertilizer, cake fertilizer, etc.

Technical parameter

Model JCZ-60 JCZ-80 JCZ-100
Power 37KW 55KW 75KW
Capacity 1-2 t/h 2-4 t/h 5-8 t/h
Dimension 4100*1600*1150mm 4250*1850*1300mm 4700*2350*1600mm
Installation Angle 2°-2.5° 2°-2.5° 2°-2.5°
Inlet Moisture Content 20%-40% 20%-40% 20%-40%
Inlet Materials Size 50 mesh 50 mesh 50 mesh

Working Principle

The new type organic fertilizer granulator uses high speed rotating mechanical shearing force and the resulting air power, making continuous implementation of the fine powder material in the machine mixing, granulating, spheroidizing, density and other processes, which achieves the goal of the granulation. The granulation method makes the pellet rate higher, and the granule is more beautiful, while saving energy and improving efficiency.

Advantage of Organic Fertilizer Mixing Granulator

1. Widely raw materials processing, especially wet raw mateirals

2. Energy saving, can be screened directly after Organic Fertilizer Mixing Granulator Manufacturer granulating

3. High granulating rate, 90% above in Cow Manure Organic Fertilizer Mixing Granulator.

4. Hard granules in ball shape, good performance

5. Stable machine running, easy operating and maintain
